Item |
Description |
|
Switching capacity |
16.00/76.80Tbps |
|
Forwarding performance |
2880/21120Mpps |
|
SRU Slot |
2 |
|
Service Slot |
6 |
|
Maximum port density |
V100R006C00 version: 288×FE,288×GE,72×10GE
V200R001C00 version: 288×FE,288×GE,240×10GE
V200R002C00~V200R007C00 version: 288×FE,288×GE,240×10GE,12×40GE
V200R008C00~V200R009C00 version: 288×FE,288×GE,240×10GE,12×40GE,12×100~GE
V200R010C00 or later version: 288×FE,288×GE,288×10GE,48×40GE,24×100GE
|
|
Wireless network
management
|
Native AC |
|
AP access control, AP region management, and AP profile management |
|
Radio profile management, uniform static configuration, and centralized
dynamic management
|
|
Basic WLAN services, QoS, security, and user management |
|
Deployment of ACs on different network layers |
|
User management |
Unified user management |
|
802.1x, MAC address, and Portal authentication |
|
Traffic- and time-based accounting |
|
User authorization based on user groups, domains, and time ranges |
|
VLAN |
Three types of interfaces: access, trunk, and hybrid |
|
Default VLAN |
|
VLAN switching |
|
QinQ and selective QinQ |
|
MAC address-based VLAN assignment |
|
MAC address |
MAC address learning and aging. |
|
Static, dynamic, and blackhole MAC address entries |
|
Packet filtering based on source MAC addresses |
|
Limit on the number of MAC addresses learned on ports and VLANs |
|
Ring Protection |
STP(IEEE 802.1d), RSTP(IEEE 802.1w), and MSTP(IEEE 802.1s) |
|
SEP |
|
BPDU protection, root protection, and loop protection |
|
BPDU tunnel |
|
ERPS (G.8032) |
|
IP routing |
IPv4 routing protocols, such as RIPv1/v2, OSPF, BGP, and IS-IS |
|
IPv6 dynamic routing protocols, such as RIPng, OSPFv3, ISISv6, and BGP4+ |
|
Multicast |
IGMPv1/v2/v3 and IGMP v1/v2/v3 snooping |
|
PIM-DM, PIM-SM, and PIM-SSM |
|
MSDP and MBGP |
|
Fast leave |
|
Multicast traffic control |
|
Multicast querier |
|
Multicast packet suppression |
|
Multicast CAC |
|
Multicast ACL |
|
MPLS |
Basic MPLS functions |
|
MPLS OAM |
|
MPLS-TE |
|
MPLS VPN/VLL/VPLS |
|
Reliability |
LACP and E-Trunk between devices |
|
VRRP and BFD for VRRP |
|
BFD for BGP/IS-IS/OSPF/static route |
|
NSF and GR for BGP/IS-IS/OSPF/LDP |
|
TE FRR and IP FRR |
|
ITU-Y.1731 |
|
DLDP |
|
QoS |
Traffic classification based on Layer 2 protocol packet header, Layer 3 protocol
information, Layer 4 protocol information, and 802.1p priority
|
|
ACL, CAR, re-mark, and scheduling |
|
Queue scheduling algorithms including SP, WRR, DRR, SP+WRR, and SP+DRR |
|
Congestion avoidance mechanisms, such as WRED and tail drop |
|
H-QoS |
|
Traffic shaping |
|
Security and management
|
802.1x authentication and portal authentication |
|
NAC |
|
RADIUS and HWTACACS authentication |
|
Different user levels for commands, preventing unauthorized users from using
certain command
|
|
Defense against DoS attacks, TCP SYN Flood attacks, UDP Flood attacks,
broadcast storms, and heavy traffic attack
|
|
Ping and traceroute |
|
RMON |
|
Service Chain |
|
Interoperability |
Supports VBST (Compatible with PVST/PVST+/RPVST) |
|
Supports LNP (Similar to DTP) |
|
Supports VCMP (Similar to VTP) |
|
Power supply |
AC:90 V to 290 V |
|
Dimensions (mm) |
442 mm x 476 mm x 442 mm
|
|
Weight |
15 kg |
|
Maximum power
consumption of the entire
equipment
|
2200 W |
|
Maximum PoE power |
8800 W
|
